Axim FC-1000 Series Universal Surface Mounted Door Closer

Brand: Axim


All prices are inclusive of VAT.

Contact us if you have any questions about our products or availability.

Axim FC-1000 Series Universal Surface Mounted Door Closer Complete with Parallel Bracket.

The Axim FC-1000 series of overhead surface mounted door closers is perfect for applications where a concealed closer is not suitable, such as bridging thermal breaks or retro-fit, the FC-1000 range of surface mounted closers provides a solution.

  • Slim line design suitable for doors that open out against adjacent walls.
  • Fire tested to BS 476-22 1987.
  • 2 closing strengths available for widths up to 800mm
  • Die cast aluminium body.
  • Suitable for single action doors, either right or left hand opening 90 and 180 degrees.
  • Reversible for standard top jamb and parallel arm installations.
  • Fixings provided for both timber and metal doors.
  • Anodised dress plates conceal fixings after installation.
  • Easy to follow instruction guide and full size template packed with every unit.
  • Silver finish.

Adjustment.

Two valve screws provide full hydraulic control from 180 degrees - 15 degrees of closing and 15 degrees - 0 degrees latching.

Accessories.

  • Hold open arm (plunger type) adjustable for any degree of retention.
  • Flat top bracket for installation on door frame when direct fixing is not possible.

  • FC-1020-P-AL = Size No. 2
  • FC-1030-P-AL = Size No. 3
